| Model | EMG9050 |
|---|---|
| Certification | ETL, FCC, HVI, CEC |
| Product Dimensions (WxDxH) (inch) | 35 1/4″ x 20 1/2″ x 25 7/16″ – 38 7/8″ |
| Power Supply(V/Hz) | 120V/60Hz |
| Max Static Pressure(Pa) | 1000Pa |
| Speed Setting | 2+Auto |
| Duct Size(inch) | 6″ Round (Top Vented) |
| MAX. EQUIV.CFM | 1300* |
| CFM(HVI) | 283 / 450 / 617 / 695 |
| Noise Level(sones) | 0.6 / 3.5 / 6.0 / 7.5 |
| Noise Level(dB) | 34 / 44 / 51.6 / 54.1 |
| Illumination(W) | 5W x 1（LED) |
| Input Power | 310W |
| Motor | DC Motor |
| Oil Cup | One Oversized |
| Oil Filter | Removable & Dishwasher Free |
| Capture Shield | Auto Height Adjustable |
| Control Type | Touch + Motion |
| Delay Shutoff | 5 min |
| Screen Lock | Y |
| Oil Filtration Rate | 94% |
| Odor Elimination Rate | 98% |
| Installation | Wall Mount |
| Duct Type | Vertical |
| Net Weight (lb) | 75.6 |
| Gross Weight (lb) | 92.1 |
| Packing-Box Size(WxDxH) (inch) | 39 5/8″ × 27 9/16″ × 24 13/16″ |
| Accessories Included | Duct Kit, Bracket, Capture Shield, Decorative Cover, Decorative Cover Bracket, Oil Cup |
| Optional Accessories | Extended Decorative Cover |
| Warranty | 5-year Limited Warranty (2-year Labor, 5-year Parts, Lifetime Motor) |
