Features
- 42″ Island Range Hood
- Tempered Glass Panel and stainless steel cover
- Touch Screen Operation
- Powered by DC motor
- Max Equiv. CFM: 1200
- 2-Min Delay shutoff
- 2 Speed Settings + Auto Turbo mode
| Model | EA06C |
|---|---|
| Certification |
ETL, CEC |
| Product Dimensions (WxHxD)(inch) |
42 15/16″ x 47 11/16″ – 70 7/16″ x 7 7/8″ (Closed) – 16 9/16″ (Fully Opened) |
| Power Supply |
120V/60HZ |
| Max Static Pressure(Pa) |
800Pa |
| Speed Setting |
2 + Auto Turbo Mode |
| Duct Size(inch) |
6″ Round (Top Vented) |
| Max Equiv.CFM | 1200* |
|---|---|
| Noise Level(dB) | 41 / 50 / 55 |
| Illumination (W) | 5W*2 (LED) |
| Motor Power (W) | 400 |
| Night Mode Lighting | Y |
| Motor | DC Motor |
| Oil Filter | Removable & Dishwasher Safe |
| Control Type | Touch |
| Delay Shutoff | 2 min |
| Intelligent Air Management | Y |
| Boost | Y |
| Smart Smoke Detection | Y |
| Cleaning Mode | Y |
| Oil Filtration Rate | 95% |
| Odor Elimination Rate | 97% |
| Installation | Island Mount |
| Duct Type | Vertical / 6 inch Round |
| Net Weight (lb) | 175.2 |
| Gross Weight (lb) | 241.4 |
| Packing-Box Size (WxDxH) (inch) | 49 5/8″ × 21 11/16″ × 53 3/16″ |
| Accessories (included) | Decorative Cover, Filter*3, Bracket, Oil Cup, Ceiling Support*2 |
| Accessories (optional) | Extended Decorative Cover (optional) |
